CARRIER

RADIATOR FOR KYMCO MXU 300 4T EURO II

TANK

(1) 11344-LCA5-E00

DUCT B LEFT COVER

(2) 11345-LCA5-E00

DUCT LEFT COVER

(3) 11346-GFY6-901

BAND LEFT COVER DUCT

(4) 11346-KKC3-900

BAND LEFT COVER DUCT

(5) 11346-LCA5-E00

DUCT LEFT COVER

(6) 11350-LCA5-E00

ELEMENT COMP LEFT COVER

(7) 17255-KKAK-900

BAND A AIR CASE CONNECTING TUBE

(8) 19005-LBA7-900

SHROUD ASSY

(9) 19010-LBA7-900

RADIATOR COMP

(10) 19012-KHD8-900

UNIT RADIATOR

(11) 19015-KKC4-900

STAY RADIATOR FAN

(12) 19018-LBA7-900

STAY UNIT RADIATOR

(13) 19020-KHD8-900

FAN COOLING

(14) 19030-LBA7-900

MOTOR ASSY FAN

(15) 19101-LBA7-900

TANK RESERVE

(16) 19102-LCA5-E01-N1R

DUCT COOLING AIR (BLACK BRUT)

(17) 19103-LBA7-900

GRID RADIATOR

(18) 19104-LBA7-900

TUBE ASSY FUEL DRAIN

(19) 19105-LCA5-E00

HOSE ASSY RESERVE TANK

(20) 1910A-LCA5-E00

TANK ASSY RESERVE

(21) 19111-GBE2-004

CAP COMP RADIATOR

(22) 19210-KKC4-900

CAP RESERVE TANK

(23) 19504-LBA7-900

HOSE COMP WATER RADIATOR OUTLET

(24) 19505-LBA7-900

HOSE COMP WATER RADIATOR INLET

(25) 19506-LBA7-900

HOSE COMP WATER

(26) 37760-KHD8-900

SWITCH ASSY THERMO

(27) 64317-LBA7-900

STAY RADIATOR UPPER

(28) 64318-LBA7-900

HOLDER LOWER RADIATOR

(29) 80130-LBA7-910

PROTECTOR MUFFLER

(30) 90302-GFY6-C00

VIS A TETE HEXAGONALE CRUCIFORME DE 08 (M05X12 NOIR)

(31) 90913-LBA7-900

TUBE WATER PUMP

(32) 93404-06012-06

BOLT HEX (M06X12)(BLACK)

(33) 93404-06016-06

BOLT HEX (M06X16)(BLACK)

(34) 93404-06020-06

BOLT HEX (M06X20)(BLACK)

(35) 93903-KEB7-900-06

SCREW TAPPING (M04X12)(BLACK)

(36) 93903-35360

SCREW TAPPING (M05X16)

(37) 94050-06060

NUT (M06)

(38) 95002-02070

CLIP (7MM)

(39) 95002-02100

CLIP (10MM)

(40) KY-99-1000

REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)

(41) 95002-KHE7-900

CLIP BREATHER TUBE

(42) 95002-KGN7-910

CLIP BREATHER TUBE

(43) 95701-06012-06

BOLT FLANGE (M06X12)(BLACK)

	Part number	Description	Qty
# 1	11344-LCA5-E00	DUCT B LEFT COVER	16,58 €(14,23 £)
# 2	11345-LCA5-E00	DUCT LEFT COVER	24,92 €(21,39 £)
# 3	11346-GFY6-901	BAND LEFT COVER DUCT	3,75 €(3,22 £)
# 4	11346-KKC3-900	BAND LEFT COVER DUCT	3,58 €(3,07 £)
# 5	11346-LCA5-E00	DUCT LEFT COVER	5,75 €(4,94 £)
# 6	11350-LCA5-E00	ELEMENT COMP LEFT COVER	6,67 €(5,73 £)
# 7	17255-KKAK-900	BAND A AIR CASE CONNECTING TUBE	3,58 €(3,07 £)
# 8	19005-LBA7-900	SHROUD ASSY	116,58 €(100,08 £)
# 9	19010-LBA7-900	RADIATOR COMP	162,42 €(139,44 £)
# 10	19012-KHD8-900	UNIT RADIATOR	14,08 €(12,09 £)
# 11	19015-KKC4-900	STAY RADIATOR FAN	17,42 €(14,96 £)
# 12	19018-LBA7-900	STAY UNIT RADIATOR	4,33 €(3,72 £)
# 13	19020-KHD8-900	FAN COOLING	5,75 €(4,94 £)
# 14	19030-LBA7-900	MOTOR ASSY FAN	129,08 €(110,82 £)
# 15	19101-LBA7-900	TANK RESERVE	14,92 €(12,81 £)
# 16	19102-LCA5-E01-N1R	DUCT COOLING AIR (BLACK BRUT)	20,75 €(17,81 £)
# 17	19103-LBA7-900	GRID RADIATOR	13,25 €(11,38 £)
# 18	19104-LBA7-900	TUBE ASSY FUEL DRAIN	4,75 €(4,08 £)
# 19	19105-LCA5-E00	HOSE ASSY RESERVE TANK	14,08 €(12,09 £)
# 20	1910A-LCA5-E00	TANK ASSY RESERVE	14,08 €(12,09 £)
# 21	19111-GBE2-004	CAP COMP RADIATOR	14,08 €(12,09 £)
# 22	19210-KKC4-900	CAP RESERVE TANK	2,92 €(2,51 £)
# 23	19504-LBA7-900	HOSE COMP WATER RADIATOR OUTLET	19,08 €(16,38 £)
# 24	19505-LBA7-900	HOSE COMP WATER RADIATOR INLET	10,42 €(8,95 £)
# 25	19506-LBA7-900	HOSE COMP WATER	5,75 €(4,94 £)
# 26	37760-KHD8-900	SWITCH ASSY THERMO	44,92 €(38,56 £)
# 27	64317-LBA7-900	STAY RADIATOR UPPER	11,25 €(9,66 £)
# 28	64318-LBA7-900	HOLDER LOWER RADIATOR	15,75 €(13,52 £)
# 29	80130-LBA7-910	PROTECTOR MUFFLER	5,75 €(4,94 £)
# 30	90302-GFY6-C00	VIS A TETE HEXAGONALE CRUCIFORME DE 08 (M05X12 NOIR)	Not available	0,00 €(0,00 £)
# 31	90913-LBA7-900	TUBE WATER PUMP	2,67 €(2,29 £)
# 32	93404-06012-06	BOLT HEX (M06X12)(BLACK)	1,33 €(1,14 £)
# 33	93404-06016-06	BOLT HEX (M06X16)(BLACK)	1,33 €(1,14 £)
# 34	93404-06020-06	BOLT HEX (M06X20)(BLACK)	1,33 €(1,14 £)
# 35	93903-KEB7-900-06	SCREW TAPPING (M04X12)(BLACK)	1,25 €(1,07 £)
# 36	93903-35360	SCREW TAPPING (M05X16)	1,25 €(1,07 £)
# 37	94050-06060	NUT (M06)	1,42 €(1,22 £)
# 38	95002-02070	CLIP (7MM)	0,92 €(0,79 £)
# 39	95002-02100	CLIP (10MM)	1,25 €(1,07 £)
# 40	KY-99-1000	REFERENCE NON RECONDUITE (NE PEUT PLUS &ECIRC;TRE COMMAND&EACUTE;E)	Not available	0,00 €(0,00 £)
# 41	95002-KHE7-900	CLIP BREATHER TUBE	1,50 €(1,29 £)
# 42	95002-KGN7-910	CLIP BREATHER TUBE	1,50 €(1,29 £)
# 43	95701-06012-06	BOLT FLANGE (M06X12)(BLACK)	1,42 €(1,22 £)

Please note that the parts offered for sale are parts from the manufacturer's catalogue, we sometimes have to order them especially for you from Kymco. Please refer to the Shipping and Delivery section for more information on delivery times.
The diagrams are not contractual, if you have any questions, our professionals are here to help and advise you as well as possible.
Select the required part number in the diagram or refer to the list above to find the information and prices relating to the different parts.
Be careful to order the required quantity when adding a part to your cart. Please note that the unit price indicated is the price for each part number in quantity 1.
Find on this page all the original spare parts relating to the RADIATOR of your Kymco MXU 300 4T EURO II of MXU. Let us know if you have any questions.
